    AC2100 Dual-Band Whole Home Mesh Wi-Fi System
    RN510 dual-band wireless AC2100 access point delivers high-speed access for web surfing and HD video streamings. Integrated with two gigabit LAN ports, and a dual-band AP which supports 2x2 802.11n(300Mbps) and 4x4 802.11ac (1733Mbps) concurrently, RN510provides a stable & reliable high speed wired and wireless connectivity for home user and
    SOHO users.
    Utilizing state of art EasyMesh solution, two or more RN510 units could be easily teamed upwith Skyworth ONT gateway (e.g. GN543) and form an automatically organized network. RN510 could support either wired line backhaul or wireless backhaul to other mesh node. User could enjoy a wonderful zero-touch, robust and failure auto recovery, seamless connected wireless home networking experience.
    RN510 uses a system of units to achieve seamless whole-home Wi-Fi coverage, eliminate weak signal areas once and for all. RN510 work together to form a unified network with a single network name. Devices automatically switch between RN510s as you move through your home for the fastest possible speeds. A RN510 Dual-pack delivers Wi-Fi to an area of up to 2,800 square feet. And if that’s not enough, simply add more RN510 to the network anytime to increase coverage. RN510 provides fast and stable connections with speeds of up to 2100 Mbps and works with major internet service provider (ISP) and modem. Parental Controls limits online time and block inappropriate websites according to unique profiles created for each family member. Setup is easier than ever with the Skywifi app there to walk you through every step.
    SPECIFICATIONSPECIFICATION

    Hardware
    Memory 128MBytes SPI NOR
    256MBytes DDR2 (CPU Built-in)
    Power Supply DC 12V 2A
    Power Consumption <15W
    Dimension(mm) 95mm*130mm*180mm(W*D*H)
    Net Weight 420g (device only)

    Wireless

    Standards

    IEEE 802.11a/b/g/n & 11ac

    Frequency Band

    2.4GHz & 5GHz

    Data Rate

    2.4GHz - 300Mbps(40Mhz)

    5GHz    - 1733Mbps(80Mhz)

    Security

    64/128bits WEP

    WPA-PSK & WPA2-PSK

    Antennas

    6*3dBi Dual Band Internal


    Firmware

    Networking

    DHCP, DNS relay, IGMP v1/v2/v3, NAT/NAPT, IPv4/v6, WPS, WMM,

    DMZ, Firewall, Port Forwarding

    Mobile APP

    Configuration tool and monitoring,

    Wi-Fi mesh node management

    Android and iOS support

    Mesh Networking

    Easy MESH Support (MAP R1.0)

    Self-Organized Network (SON)

    Auto Configuration

    Seamless Roaming

    User Load Balancing

    Auto Healing

    Band/Channel Steering


    Interface&Enviroment

    LEDs

    One indicator with 4 colors

    Buttons

    Reset, WPS

    Network

    2*GbE RJ45 ports

    Power Jack

    12V DC Jack

    Operating Temp.

     0 ~ 45¡æ (32~113¨H)

    Storage Temp.

    -20 ~ 65¡æ (-4 ~149¨H)

    Operating Humidity

    10% ~ 90% non-condensing
